Gas Liquid Metal Sintered Porous Filter With High Temperature / Corrosion Resistance

Name: Gas Liquid Metal Sintered Porous Filter With High Temperature / Corrosion Resistance
Brand: changsheng
SKU: None
Price: 20 USD
Availability: InStock
Rating: 4.8 (179 reviews)

Large Image : Gas Liquid Metal Sintered Porous Filter With High Temperature / Corrosion Resistance

Product Details:

Place of Origin:	Baoji, China
Brand Name:	changsheng
Certification:	SGS, ISO
Model Number:	None

Payment & Shipping Terms:

Minimum Order Quantity:	10 PCS
Price:	USD20-100
Packaging Details:	Vacuum Packaging+Wooden Case, Vacuum Packaging+Carton Case
Delivery Time:	5-10 Days
Payment Terms:	T/T, L/C, PayPal, Alibaba Secure Payment
Supply Ability:	2000PCS/Month

Contact Now

Detailed Product Description

Material:	Stainless Steel	Type:	Filter Cylinder
Usage:	Gas, Liquid	Filter Rating:	0.5um-70um
Abrasion Resistance:	High	Filter Rating:	0.2-100 Microns
Filtration Efficiency:	High	Flow Rate:	High
Pressure Resistance:	High	Size:	Customized
Highlight:	Liquid Metal Sintered Porous Filter , 2.5mm Porous Metal Filter , Corrosion Resistance Metal Sintered Porous Filter

Nickel Base Alloy Sintered Porous Filter High Mechanical Strength Precise Dimension

Powder Sintered Filter Elements Specification
Material	OD	Penetrability	Wall Thickness	Micron Rating	Limited Pressure	Connector
Titanium Stainless Steel Nickel Baiss	Φ18,Φ20, Φ25,Φ30, Φ40,Φ50, Φ55,Φ60, Φ70,Φ75, Φ80	3-800m3/m2hKpa	2.5-3mm	Titanium: 5-100um Stainless Steel: 0.5-100um	2.5-3 Mpa	M20, M30, 222, 226, NPT, DOE

Production Range Of Metal Sintered Products
Material	Filter Rating	Porosity	Penetrability	Working Pressure	Operating Temperature	Production	Specific Surface Area
Stainless Steel Powder 304, 316, 316L	0.5-100um	30-45%	3-1300m3/m2hKPa	2.0-3Mpa	600℃	Plate, Disc	10-40cm2/cm3

Properties of stainless steel sintered porous materials:

High-temperature resistance, in normal use under 500 ℃.
High mechanical strength, good plasticity, can be machined.
Corrosion resistance, oxidation resistance, can be used in nitric acid, sulfuric acid, dilute hydrochloric acid (5%), acetic acid, liquid hydrogen, liquid nitrogen environment.
Good molding process, according to customer drawings for processing a molding.
High filtration precision and good purification effect.
The pores are uniform, the internal structure is stable, and no particles fall off.
Good air permeability, easy to back blow cleaning, can be used repeatedly online regeneration.
Wear resistance and impact resistance, good mechanical properties.

Application of stainless steel sintered porous materials

According to its physical and structural characteristics, stainless steel sintered porous materials are mostly used in the fields of noise elimination, filtration and separation, fluid distribution, flow-limiting, capillary core and so on.

The chemical raw material production process in addition to impurity filtration, material decarburization filtration, and fine filtration.
Ultrafiltration, RO, EDI system security filtration in water treatment.
The food and beverage industry finished product clarification filtration.
Filtration and recovery of the precious metal catalyst in the petrochemical industry.
Precision filtration of liquid raw materials, products and pharmaceutical intermediates in the chemical industry.
Reverse osmosis security filtration in the field of water injection filtration.
Gas purification of steam, compressed air deoiling purification.
Medium purification and flow limitation for pneumatic components, lubricants, fuels, and hydraulic pressure systems.
Chemical dye industry of high - temperature decarburization.

Precautions for the use of stainless steel sintered porous materials

During installation, disassembly and clean avoid scratches, collisions and falls on hard objects.
When using, the filtrate is filtered from the outside in to avoid the reverse direction.
Avoid instant pressurization when the filter element works.
When the filtration efficiency is less than 50%, the filter element should be cleaned in time.
When cleaning the filter element, the first backflow with pure gas, back blow pressure is 1.5 times the working pressure, each time for 3-5 seconds, and 4-6 times, then backwash with clean liquid for 3-5 minutes, repeat 2-3 times.
If the filter element is not good after online back blowing and backwashing, it should be removed and cleaned in time.
